Tripp Lite SMART2200RMXL2U UPS System

UPC Code: 037332118059
Manufacturer Warranty: 2 YEARS
D&H Returns Allowed: no
Return Period (Days): 0
Add'l Return Info: Past Exchange-Call Tripplite 773-869-1234
Master Pack Qty: 1
Country of Origin: TAIWAN

General Information

Manufacturer:   Tripp Lite by Eaton
Manufacturer Part Number:   SMART2200RMXL2U
Manufacturer Website Address:   www.tripplite.com
Brand Name:   Tripp Lite
Product Line:   SmartPro
Product Name:   SMART2200RMXL2U UPS System
Marketing Information:   Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption or reboot. 96% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support communications via USB, RS-232 and slot for optional Network Management Card. HID-compliant USB port enables integration with built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility power conditions. PowerAlert UPS monitoring software is available via free download. Switched output load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules.

More from the Manufacturer

Packaged Quantity:   1 Each
Product Type:   Line-interactive UPS

Technical Information

Plug/Connector Type:   NEMA 5-20P
Receptacle Type:   NEMA 5-15R
Receptacle Type:   NEMA 5-20R
Receptacle Detail:   4 x NEMA 5-15R
Receptacle Detail:   4 x NEMA 5-20R
Protection Type:   Over Voltage
Protection Type:   Under Voltage
Emergency Power OFF:   Yes
Cord Length:   10 ft
Transfer Time:   4 ms

Power Description

Load Capacity:   2.20 kVA/1.92 kW
Input Voltage:   120 V AC
Output Voltage:   110 V AC
Output Voltage:   120 V AC
Waveform Type:   Sine Wave

Management

Network Management:   SNMP Manageable
Alarm:   Low Battery
Alarm:   On Battery
Alarm:   Overload

Controls/Indicators

Status Indicators:

5 Front Panel Leds:

• Green Power Led
• Green Voltage Correction Led
• 3 Color Battery Charge Led
• 3 Color Output Load Led
• Red Battery Warning Led

Interfaces/Ports

Serial Port:   Yes
USB:   Yes

Battery Information

Backup/Run Time (Full Load):   4.50 Minute
Backup/Run Time (Half Load):   12 Minute
Typical Battery Recharge Time:   4.50 Hour
Hot Swappable:   Yes

Environmental Conditions

Maximum Operating Temperature:   104°F (40°C)

Physical Characteristics

Height:   3.50" (88.90 mm)
Width:   17.50" (444.50 mm)
Depth:   19" (482.60 mm)
Rack Height:   2U
Weight (Approximate):   29.03 kg

Miscellaneous

Package Contents:

• SMART2200RMXL2U UPS System
• Poweralert Software CD-ROM
• USB, Serial And EPO Cabling
• Owner's Manual

Certifications & Standards:

• UL1778 (USA)
• CSA (Canada)
• NOM (Mexico)
• FCC Part 15 Category A (EMI)

Recycled:   No
Environmentally Friendly:   Yes
Environmental Certification:   RoHS
Country of Origin:   China

Warranty

Limited Warranty:   3 Year
