MSI Z690-P DDR4 Desktop Motherboard - Intel Z690 Chipset - Socket LGA-1700 - Intel Optane Memory Ready - ATX

UPC Code: 824142274118
Manufacturer Warranty: 3 Years
D&H Returns Allowed: no
Return Period (Days): 0
Add'l Return Info: Past Exch Call 888-447-6564
Master Pack Qty: 20
Country of Origin: CHINA

General Information

Manufacturer:   MSI
Manufacturer Part Number:   PROZ690PDDR4
Manufacturer Website Address:   www.msi.com
Brand Name:   MSI
Product Series:   PRO
Product Model:   Z690-P DDR4
Product Name:   PRO Z690-P DDR4 Desktop Motherboard
Marketing Information:

THERMAL SOLUTION FOR MORE CORES AND HIGHER PERFORMANCE
With more cores' processors, thermal and power design is more important to make sure the temperature keeps lower. MSI extended PWM heatsink with 7W/mK thermal pad ensures even high-end processors to run in full speed with MSI motherboards.

Product Type:   Desktop Motherboard

Processor & Chipset

Chipset Manufacturer:   Intel
Chipset Model:   Z690
Total Processor Supported:   1
Processor Socket:   Socket LGA-1700
Processor Generation Supported:   12th Gen
Processor Supported:   Celeron
Processor Supported:   Core i3
Processor Supported:   Core i5
Processor Supported:   Core i7
Processor Supported:   Core i9
Processor Supported:   Pentium Gold
Multi GPU Supported:   CrossFire

Memory

Number of Memory Slots:   4
Memory Form Factor:   DIMM
Memory Form Factor:   UDIMM
Maximum Memory Supported:   128 GB
Memory Technology:   DDR4 SDRAM
Memory Speed Supported:   2133 MHz
Memory Speed Supported:   2400 MHz
Memory Speed Supported:   2666 MHz
Memory Speed Supported:   2933 MHz
Memory Speed Supported:   3200 MHz
Memory Speed Supported:   3333 MHz
Memory Speed Supported:   3400 MHz
Memory Speed Supported:   3466 MHz
Memory Speed Supported:   3600 MHz
Memory Speed Supported:   3733 MHz
Memory Speed Supported:   3800 MHz
Memory Speed Supported:   4000 MHz
Memory Speed Supported:   4200 MHz
Memory Speed Supported:   4266 MHz
Memory Speed Supported:   4400 MHz
Memory Speed Supported:   4600 MHz
Memory Speed Supported:   4800 MHz
Memory Speed Supported:   5000 MHz
Intel Optane Memory Ready:   Yes

I/O Controller

Controller Type:   Serial ATA/600
RAID Supported:   Yes
RAID Levels:   0
RAID Levels:   1
RAID Levels:   10
RAID Levels:   5

Video

Onboard Video:   CPU Dependent Video

Audio

Audio Channels:   7.1

Network & Communication

2.5Gigabit Ethernet:   Yes

I/O Expansions

Number of Total Expansion Slots:   5
Total Number of PCI Express Slots:   5
Number of PCI Express x1 Slots:   3
Number of PCI Express x16 Slots:   2

Interfaces/Ports

Total Number of USB Ports:   7
Number of USB 2.0 Ports:   2
Number of USB 3.2 Ports:   1
Number of USB 3.2 Gen 1 Ports:   4
S/PDIF:   Yes
HDMI:   Yes
DisplayPort:   Yes
Number of Network (RJ-45) Ports:   1

Onboard Interfaces

Number of SATA Interfaces:   4
Number of M.2 Interfaces:   2
Total Number of Onboard USB Ports:   8
Number of Onboard USB 2.0 Ports:   4
Number of Onboard USB 3.2 Ports:   4

Physical Characteristics

Form Factor:   ATX
Width:   12" (304.80 mm)
Depth:   9.60" (243.84 mm)

Miscellaneous

Package Contents:

• PRO Z690-P DDR4 Desktop Motherboard
• Quick Installation Guide
• 2 x SATA Cables
• M.2 Screw / Standoff Sets
• Product Registration Card
• I/O Shield
• Driver DVD

Brand Compatibility:   Intel
Country of Origin:   China

Warranty

Limited Warranty:   3 Year
